Pistol grip, magazine screwdriver with ratchet and bits

Pistol ratchet multi-bit scrwdriver with bits
SCRDRIV-MULTIBIT-REVOLVER-RTCH-VAR1-8PCS
ZEBRA

Art.-no. 06136301
EAN 4047376855403

Prices for customers after login

Exclusively for registered customers

Register now and access more than 20,000 products

3 in 1: Pistol grip, screwdriver handle with ratchet, magazine with 7 bits

Blade: Short bit holder blade with magnet, bright chrome-plated


The short bit holder blade makes it ideal for use in hard-to-reach screwing situations



Tip: DIN 3126-D 6.3



2C pistol grip for optimum ergonomic work


Can be used as a standard screwdriver in the straight position or as a pistol grip in the 60° position thanks to the adjustable handle



High-performance ratchet screwdriver


  • 45 teeth, max. torque of up to 40 Nm

  • 3-position adjustment wheel, one-handed direction change

  • Magnet ensures a secure grip on bits and screws


Sealing cap with bit magazine for six bits


  • Storage space in handle, 1/4" bits
Product information

Datasheets(X)

Certificates/ Documents

 |

 |

Material of handle

2-component plastic

Tip size

D 6.3 (1/4 inch)

Tip type

Hexagon socket

Max. torque

40 Nm

Number of teeth

45 PCS

Number of bits

7 PCS

Handle width (A3)

39 mm

Blade length (B)

35 mm

Handle length (D)

128 mm

including:
1 x

SCRDRIV-MULTIBIT-REVOLVER-RTCH-EMPTY

ZEBRA
Description: 3 in 1: Pistol grip, screwdriver handle with ratchet and bit magazine (empty)
Quantity: 1 x
1 x

BIT-SL-0,8X5,5-1/4IN-L25MM

Description: 25 mm long, in all common blade thicknesses x blade widths
Quantity: 1 x
1 x

BIT-PH1-YELLOW-1/4IN-L25MM

Description: With colour-coding
Quantity: 1 x
1 x

BIT-PH2-WHITE-1/4IN-L25MM

Description: With colour-coding
Quantity: 1 x
1 x

BIT-HEXSKT-WS4-1/4IN-L25MM

Quantity: 1 x
1 x

BIT-HEXSKT-WS5-1/4IN-L25MM

Quantity: 1 x
1 x

BIT-TX10-BLUE-1/4IN-L25MM

Description: Short design for all common TX screw sizes
Quantity: 1 x
1 x

BIT-TX20-WHITE-1/4IN-L25MM

Description: Short design for all common TX screw sizes
Quantity: 1 x
